Technical specifications
Glass plate size （ W×L ) : 216×220 mm
Gel Size （ W×L ） : 186×205 mm
Gel thickness: 1.0 （ mm ）
Gel amount: 1 ～ 2 （ pieces ）
Sample volume: （ 1.0mm ） 25 , 40 , 52wells
Buffer Volume: ～ 3500 （ ml ）
Dimension （ L×W×H ） : 280×140×250 （ mm ）
Net weight: 5.6 （ kg ）
Characteristic features
• The installation of the glass plate in just 15 seconds, and does not need the knob, fast and convenient.
• With the gel making device of normal position, don’t should to moving the glass plate from the process of making the gel to electrophoresis.
• With the Precast gel inner core, do not affect the operation of
gel making while the electrophoresis.
• Safety cover open button design, convenient opening the cover.
• Abundant buffer not only guarantees cooling effects but also keeps the pH Value stable during the whole experiment process.
• Auto-switch-off when the lid is removed.
