Technical specifications
Glass plate size（W×L）: 216×220 mm
Gel Size（W×L）: 186×205 mm
Gel thickness: 1.0（mm）
Gel amount: 1～2（pieces）
Sample volume: （1.0mm）25、40、52wells
Buffer Volume: ～3500（ml）
Dimension（L×W×H）: 280×140×250（mm）
Net weight: 5.6（kg）
Characteristic feature
• The installation of the glass plate in just 15 seconds, and does not need the knob, fast and convenient.
• With the gel making device modular, you can make multi slab gel at the same time.
• Safety cover open button design, convenient opening the cover.
• Abundant buffer not only guarantees cooling effects but also keeps the pH Value stable during the whole experiment process.
• Auto-switch-off when the lid is removed.
