NP-2032 is a fully automatic nucleic acid extraction instrument launched by Ningbo Scientz based on the needs of clinical large- scale genetic analysis. This machine uses magnetic bead separation technology, according to the selection of the appropriate kit to separate and purify nucleic acids in multi-source samples (such as blood, animal and plant tissues, cells). The entire instrument has stable performance and low noise, and the operation is automated, fast and simple. It can simultaneously purify 32 samples. A powerful “assistant” in clinical genetic testing and molecular biology laboratory research.
WORKING PRINCIPLE
Use the magnetic rod on the magnetic rod holder in the machine to move the magnetic beads with adsorbed nucleic acids to different reagent tanks, and then use the magnetic rod sleeve placed on the outer layer of the magnetic rod to repeatedly move the liquid up and down to mix it evenly. Lysis, nucleic acid adsorption, washing and elution, to obtain the purest nucleic acid.
Flexible control Large screen full color display, touch operation, easy to use Customizable shortcut program, one-click startup
Humanized observation window and display screen design, easy to operate
FEATURES
- Fast and efficient
Purified nucleic acid purity can meet the needs of various downstream experiments Nucleic acid recovery rate> 95%, magnetic bead recovery rate> 95%
Total extraction of 32 samples can be completed in about 20-40min (depending on reagents). - Safe and reliable
Fully automatic operation with disposable consumables to reduce personnel contact Built-in regular UV disinfection, efficient cleaning
Exhaust fan to effectively avoid aerosol pollution
Prevent door opening alarm and automatically stop the movement structure during operation to ensure safe operation. - Strong versatility
Multi-speed and multi-module for selection, and can store 100 programs to meet different customer requirements Custom lysis and elution temperature
Suitable for different samples, such as animal and plant tissues, serum, plasma, etc. - Flexible control
Large screen full color display, touch operation, easy to use Customizable shortcut program, one-click startup
Humanized observation window and display screen design, easy to operate
TECHNICAL PARAMETERS
| Model | NP-2032 | |||||
| Sample throughput | 1 ~ 32 | |||||
| Processing volume | 30-1000ul | |||||
| Magnetic bead recovery rate | > 95% | |||||
| Number of magnets | 32 | |||||
| Purification sensitivity | Positive detection rate of 100 copies sample> 95% | |||||
| Purify the difference between pores | CV <3% | |||||
| Consumables | 96 deep well plate + magnetic rod sleeve | |||||
| Cracking temperature | Room temperature to 120 °C | |||||
| Elution temperature | Room temperature to 120 °C | |||||
| Concussion mixing | ||||||
| Operation interface | 7-inch touch screen, 8 shortcut program files | |||||
| Internal program Preset | 8 programs, can store 100 programs | |||||
| Program management | New, edit, delete, save as, etc. | |||||
| Instrument Expansion Interface Standard | USB | |||||
| Lighting System | Yes | |||||
| Disinfection | UV disinfection | |||||
| Exhaust method | Fan | |||||
| Data storage can be stored | built-in SD card | |||||
| Size | 422x422x470 (mm) | |||||
