Desc:
L1200 series biological microscopes are equipped with achromatic objectives and wide field eyepieces. They have clear image, wide field, etc. They can be used for biology, medicine, and agriculture and industry area widely. They are the ideal instruments in medical treatment,teaching demonstration and scientific research.
Features
▲ With wide field eyepieces and plan achromatic objectives, the field of view is widely and clear.
▲ Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
▲ 6 Volt 20 Watt Halogen lamps with brightness control
Standard Configuration:
|
Model
|
L1200A
|
L1200B
|
L1200C
|
||
|
Eyepiece
|
Wide field WF10X(Φ18mm)
|
||||
|
Objective
|
Achromatic 4X/0.10
|
Achromatic 4X/0.10
|
Achromatic 4X/0.10
|
||
|
Achromatic 10X/0.25
|
Achromatic 10X/0.25
|
Achromatic 10X/0.25
|
|||
|
Achromatic 40X/0.65(Spring)
|
Achromatic 40X/0.65(Spring)
|
Achromatic 40X/0.65(Spring)
|
|||
|
Achromatic 100X/1.25(Spring, oil)
|
Achromatic 100X/1.25
(Spring, oil)
|
Achromatic 100X/1.25(Spring, oil)
|
|||
|
Eyepiece tube
|
Binocular(Inclination of 30˚)
|
||||
|
Focus system
|
Coaxial coarse/fine focus system. Minimum division of fine focusing: 2μm
|
Coaxial coarse/fine focus minimum division of fine focusing: 2μm, with tensional adjustable and up stop, base bearing black plastic cap
|
Coaxial coarse/fine focus with tensional adjustable and up stop, minimum division of fine focusing: 2μm.
|
||
|
Nosepiece
|
Quadruple(Backward ball bearing inner locating)
|
||||
|
Stage
|
Double layer mechanical (Size:135mmX125mm, Move range: 75mmX35mm)
|
||||
|
Abbe condenser
|
N.A.1.25 Rack & pinion adjustable
|
||||
|
Filter
|
Blue filter
|
||||
|
Frosted filter
|
|||||
|
Collector
|
For halogen lamp
|
For halogen lamp
|
For halogen lamp
|
||
|
Light source
|
6V 20W, Halogen lamp with brightness control
|
||||
