Technical specifications
Gel Size ( W×L : 48×75mm
Sample volume: 3, 5, 9.
Buffer Volume: ~150ml.
Dimension ( L×W×H: 250×90×50 ( mm )
Net weight: 0.4 ( kg )
Characteristic feature
• Abundant buffer not only guarantees cooling effects but also keeps the pH Value stable during the whole experiment process.
• Unfolded electrodes make the repair and parts replacement easy and quick.
• With the sample background color design on the tray, convenient to adding the sample.
• The transparent top lid effectively prevents liquid in the cell from volatilizing and avoids electricity leakage.
• Auto-switch-off when the lid is removed.
