Description

Digital microscope
projectparameter
Image sensor1/6″ color CMOS image sensor
Resolution640*480, VGA, QVGA
Data FormatMJPG/YUY2
Output formatDynamic: AVI/YUY2
Static: BMP/JPEG
Focus modeManual
Pixel size640*480
Frame rate25F/s
Minimum illumination0.1Lux
White balanceAuto
Drive typeUvc
CDEmbedded Drive Measurement Software User Manual
light sourcePositive white LED
Working current450mA maximum
Lens structure5G
System SupportWin10 Win8 Win7 Vista Win XP LINUX
power inputUSB-5V
Signal transmission methodUSB2.0
Operating temperature-20°C—75°C
Working humidity30%~90% Rh
Body size112MM (long) 33MM (outer diameter)
Machine weight / color box size250g (including color box) / 150MM * 125MM * 45MM
Packing quantity/weight per case50 units / 13.2kg
Carton size640mm*312*245mm
