Features:
* Newest generation peltier-based technology, more steady, reliable and durable with ramping rate at 5.5℃/sec.
* 7 inches color full touch screen, graphical display of protocols.
* Bilingual interface (English and Chinese).
* Download and upgrade software through flash drive.
Technical Parameters:
Model | BK-GR600 | |
Gradient Module | Block | 6*16 wells *0.2 individual module |
Six different annealing temperatures could be set for each zone | ||
Tube Type | 0.2ml PCR tubes, 8/12 strips, 96 wells PCR plate | |
Peltier Technology | NewGenerationPeltierTechnology | |
Display | 7 inches color touch screen, graphically display the realtime protocols and running status | |
Language | Full English | |
Communications Ports | 2 USB and 1 LAN | |
Venting System | Front air in and back air out, two cyclers can be placed side by side | |
Temperature | Block Temperature Range | 0℃~105℃ |
Max. Heating Rate | 5.5℃/s | |
Max. Cooling Rate | 4.5℃/s | |
Temperature Uniformity | ≤±0.15℃ | |
Temperature Accuracy | ≤±0.10℃ | |
Display Resolution | 0.10℃ | |
Ramping Rate Adjustable | Yes | |
Mode of Temperature Control | Sim-tube & Block mode | |
Gradient | Gradient Accuracy | ≤±0.15℃ |
Zone Uniformity | ≤±0.20℃ | |
Gradient Range | 0℃~105℃ | |
Temperature Differential Range | Less than 25℃ between two adjacent zones | |
Gradient Capability | 6-zone temperature can be set independently, better than traditional gradient function | |
Software | Max. No. of Programs | Max. 15,000 programs onboard, unlimited storage of protocols with USB flash drive |
Max. Step | 30 steps, multiple nesting cycle available | |
Max. Cycle | 100typical cycles, max. 60,000 nesting cycles | |
Time Increment/Decrement | 1~120 sec, available forlong PCR &touchdown PCR | |
Temperature Increment/Decrement | 0.1~10.0℃, available for touchdown PCR | |
Auto Pause / Auto Restart | Yes | |
Multi-userLog in | With password-based authentication prevents from view, copy and alteration of protocols | |
Tm Calculator | Automatically calculate the melting and annealing temperature with two primer sequences | |
Hold at 4℃ | Yes, an infinite incubation time at low temperature for overnight working | |
Program Wizard | Yes, create PCR protocols with only a few clicks | |
Running Report | Yes, provide precise information for the whole experiment | |
PC Connection | Yes, PC remote control to manage multi units across the newwork | |
Heat Lid | Height of Heat Lid | Steplessly adjustable Lid, accommodates all kinds of PCR tubes, strips and plates |
Lid Feature | Innovative “TOP-OPEN” technology, protection from over- pressure | |
Heat Lid Temperature Range | 30℃~112℃ | |
Auto Shut-off | Yes | |
Others | Power Supply | 85V-265V, 50-60Hz Max. 600W |
Package Size(L*W*H) | 362*256*255mm | |
Net Weight | 7.3kg |
