Key Features
• Maintenance free brushless DC motor
• Max. temperature to 340°C
• Stirring speed up to 1500 rpm
• Stainless steel work plate with ceramic coating provides good chemical-resistant performance
• Safety circuits provide overheating protection
• A wide variety of accessories are available.
| Specifications | MS-H-S |
| Work plate dimension | φ135mm(5 inch) |
| Work plate material | stainless steel cover with ceramic |
| Motor type | Brushless DC motor |
| Stirring positions | 1 |
| Max. stirring quantity[H2O] | 20L |
| Max. magnetic bar[length] | 80mm |
| Speed range | 0-1500rpm resolution±1rpm |
| Speed display | Scale |
| Temperature display | Scale |
| Heating temperature range | Room temp.-340°C |
| Temperature control accuracy | — |
| Over temperature protection | 420°C |
| Temperature display accuracy | ±0.5°C |
| External temperature sensor | — |
| Hot warning | — |
| Timer function | — |
| Data connector | — |
| Protection class | IP42 |
| Motor rating input | 18W |
| Motor rating output | 10W |
| Power | 550W |
| Heating output | 500W |
| Voltage | 100-120/200-240V 50/60Hz |
| Dimension[WxDxH] | 160×280×85mm |
| Weight | 2.8kg |
| Permissible ambient temperature and humidity | 5-40°C, 80%RH |
| Cat. No. | P/N | Descriptions | Power supply |
| 8030211010 | MS-H-S | Classic Hotplate Magnetic Stirrer，stainless steel with ceramic coated hotplate，heating temperature up to 340°C | USA plug,100V-120V/50Hz/60Hz |
| Cn plug,200V-240V/50Hz/60Hz | |||
| Euro plug,200V-240V/50Hz/60Hz | |||
| UK plug,200V-240V/50Hz/60Hz |
