Specification
  • Main parameters
    Total magnification
    100X (standard configure)
    Mechanical tube length
    Conjugate distance of objective
    Eyepiece
    achromatic Wide-field plan eyepiece
    SWF 10X
    field of view number
    Ф22mm
    Eyepiece interface
    Ф30mm
    Parfocal distance
    10mm
    Trinocular
    Observation angle of 30° with photography port,spectro rate 8:2(eyepiece:photography)
    Strain-free plan achromatic objective
    Magnification
    Numerical aperture
    Working distance (mm)
    Thickness of cover glass (mm)
    Remarks
    10X
    0.25
    20.2

    Analyzer
    Insert type,can be switch freely,the direction of polarization has preset, no use for adjust
    Polarizer
    Insert type,can be switch freely,360°rotatable
    DIC Slider
    DIC slider matching 5X/10X/20X objective,horizontal adjustable
    X-Y Stage
    double layer mechanism stage, size:180 X 145mm,moving range:35X 30 mm(X-Y)
    Vertical availability distance
    Focus system available distance 133mm, observational specimen maximal thickness up to 130mm.
    focus system
    Coaxial coarse/fine focus system, minimum division of fine focusing: 2μm
    Illumination
    Coaxial illumination using high brightness white LED. Brightness adjustable
    Main power sullpy
    AC:85V~265V 50/60Hz,fuse specification:250V 3.0A
    Accessory (optional)
    Objective
    20X strain-free plan achromatic objective,NA:0.40,working distance:8.0mm
    Digital camera
    130、300、500、1000mega pixels,with image analysis software.
