Description:
L500 series biological microscopes are equipped with monocular, achromatic objectives and wide field eyepieces. They have provides clearimage, wide field, convenience operation. They can be used for medicine agriculture area widely. They are the ideal instruments in medicaltreatment, teaching demonstration.
Features
▲ With wide field eyepieces and achromatic objectives, the field of view is widely and clear
▲ Separate coarse/fine system focus or coaxial coarse/fine focus system can be chosen, minimum division of fine focusing: 4μm
▲ Separate coarse/fine system focus or coaxial coarse/fine focus system can be chosen, minimum division of fine focusing: 4μm
▲ 220V/110V 20W incandescent lamp transmission illumination.
Specification
Standard Configuration:
|
Model
|
L500A
|
L500B
|
|
Eyepiece
|
Wide field WF10X(Φ18mm)
|
|
|
Objective
|
Achromatic 4X/0.10
|
|
|
Achromatic 10X/0.25
|
||
|
Achromatic 40X/0.65(Spring)
|
||
|
Eyepiece tube
|
Monocular,360˚ rotatable (Inclination of 45˚)
|
Monocular,360˚ rotatable (Inclination of 45˚)
|
|
Focus system
|
Separate coarse/fine system focus. Minimum division of fine focusing: 4μm
|
Coaxial coarse/fine focus system. Minimum division of fine focusing: 4μm
|
|
Nosepiece
|
Triple(Frontward ball bearing outer locating)
|
|
|
Stage
|
Fixed(Size:120mmX120mm, With single lens and iris diaphragm)
|
|
|
Filter
|
Blue filter
|
|
|
Frosted filter
|
||
|
Collector
|
For incandescent lamp
|
|
|
Light source
|
220V/110V 20W, Incandescent lamp
|
|
