Product Overview
Features:
◎ Designed for screening and testing of syphilis RPR,TRUST, VDRL, also can be used for mixing of various kinds of petri dish, elisa plates etc.
◎ High performance DC motor, Quiet, Stable and long lifetime.
◎ Digital time and speed set makes the control more accurate, except KJ-201BH.
◎ KJ-201BX, Fixed transparent cover type or Non-cover type available.
◎ LED screen for time and speed display, easy for reading and operation, except KJ-201BH.
◎ Wide voltage design avoids the impact of unstable voltage on the equipment.
Spec:
| Model | KJ-201BE | KJ-201BX | KJ-201BH |
| Operation method | Circling | Circling | Circling |
| Circling diameter | 20mm / 22mm | 20mm / 22mm | 20mm / 22mm |
| Max. Loading | 1kg | 1kg | 1kg |
| Speed range | 40-230rpm | 40-230rpm | 20-210rpm |
| Timing range | 1~999min | 1~999min | 0~15min/0~60min |
| Running mode: | Timing/Continuous | Timing/Continuous | Timing/Continuous |
| Input voltage(frequency): | AC100-240V(50/60Hz) | AC100-240V(50/60Hz) | AC100-240V(50/60Hz) |
| Input power: | 10W | 10W | 10W |
| Working plate size: | 302×212mm | 280×210 (Common type) 245×167 (With cover) |
302×212mm |
| Protective class: | IP21 | IP21 | IP21 |
| Permissible ambient temperature: | 5-50°C | 5-50°C | 5-50°C |
| Permissible relative moisture: | 80% | 80% | 80% |
| Dimensions: | 330×320×110mm | 330×320×110mm | 330×320×110mm |
| Net. Weight: | 4.2Kg | 4.5Kg | 4.6Kg |
