Mainly applied in a variety of fields such as biochemistry,medical treatment and public health,food safety,life science,forestry,animal husbandry,blood banks,blood stations,biological products and pharmaceutical products.It is the ideal equipment for separation,precipitation,concentration and preparation of samples and a high-tech product than can compare favorably with import ones and be exported in large quantities.
Features:
- With TFT true-color LCD wide-screen touch monitor featured by intelligent control,easy and convenient operation,a touch panel and a simultaneous indication of both the set parameters and operation ones.
- Use a brushless motor with high torque and variable frequency which is controlled by an SCM of Microchip’s dsPIC30F Series and driven by a special driver module of FAIRCHILD’s FSBB30CH Series to ensure the circuit’s reliability.
- The design of the whole machine is in line with the ergonomics.with a streamline design,a complete steel structure and a stainless steel centrifuge cavity,it is safer,better looking and more efficient.
- With multiple protection measures such as super speed,over heat and imbalance as well as a special combination of shock absorbers to keep the motor running smoothly.With triple protective layers of steel bushing to achieve secure and reliable operation as well as personnel and equipment safety.
- Rotors at rest will be in standby and cool down.
- With a dedicated key indicating the centrifugal force which has the inching function for momentary centrifugation.
- With a motor gate lock mute mechanical & electrical integration.
- Able to provide more than 20 kinds of operating modes for the user to programme and use freely.
- 10 levels for speed-up and speed-down control.
- Maximum rotation speed:20600r/min,Maximum capacity:4x750ml.
| Model | HR26M |
| Standard rotor | Swing rotor 4×750ml |
| Max Capacity | 12×1.5/2.0ml |
| Max Speed（r/min） | 20600r/min |
| Speed precision | ±50r/min |
| Max RCF（×g） | 29400×g |
| Refrigeration system | Import fluoride-free compressor and control valve（R404a） |
| Temp.control range | －20℃～40℃ |
| Temp.precision | ±1℃ |
| Temp.control range | -20℃～+40℃ |
| Temp.precision | ±1℃ |
| Operation pro grame | 20 |
| Temp.control range | Frequency motor，micro control，direct driver |
| Total power | 2kw |
| Timer range | 0-99h59min |
| Noise | ≤65dB |
| Power | AV220V 50Hz |
| weight | 110 kg |
| Dimension（L×W×H） | 710×560×770mm |
| Model | capacity | HR/T20MM | |
| Speed（r/min） | RCF(×g) | ||
| Angle rotor | 12×1.5/2.0ml | 20600 | 29400 |
| Swing rotor | 4×750ml | 4000 | 3500 |
| 4×500ml | 4000 | 3580 | |
| Adpator | 4×250ml | ||
| 4×8×15ml | |||
| 4×12×10ml | |||
| 4×3×50ml | |||
| 4×19×5ml | |||
| （vacuum tube） | |||
| 24×1.5/2.0ml | 14000 | 18180 | |
| 12×10ml | 14000 | 18800 | |
| 6×50ml | 12000 | 13800 | |
| 4×100ml | 10000 | 10500 | |
| 6×100ml | 11000 | 14520 | |
| 6×250ml | 8000 | 9200 | |
| Swing micro-plate rotor | 2×2×96 hole | 4000 | 2360 |
