SPECIFICATIONS
Introduction
● Host English operating system, 10-inch color touch screen display
● M-2800S successful implementation of the stringent requirements of high accuracy and reliability measurement to meet the requirements of various applications that can be used in biological research, bio-industry, pharmaceutical analysis, pharmaceutical, teaching and research, environmental protection, food hygiene, clinical examination, health and epidemic prevention and other fields.
● A wide wavelength range, the wavelength range to meet the various requirements of the field.
● The design of LSI greatly improves the scalability and reliability of the system
● Improved optimization of the optical design, import source and receiver system created a high performance and high reliability.
● Rich measurement methods, with a wavelength scan, time scan, multi-wavelength determination, multi-order derivative determination (optional), dual-wavelength, three-wavelength (optional) DNA protein measurements (optional), and other measurement methods to meet different measurement requirements, and can be displayed directly on a 10-inch screen.
● Based on user requirements optional hole rack, manual four with stand, manual Eighth rack, automatic Eighth frame, glass stand, test tube rack, 1cm colorimetric frame, 5cm colorimetric frame
● Support external U disk storage and transmission of experimental data.
● Can be powered down to save the measurement parameters and data, user-friendly.
● Can achieve more accurate and flexible measurement via PC control, which can meet the needs of different users.
Spec:
| Optical path structure | Double beam spectrophotometer |
| Wavelength Range | 190~1100nm |
| Band Width | 0.5/1.0/2.0/4.0/5.0nm adjustable |
| Wavelength Accuracy | ±0.3nm |
| Wavelength Repeatability | 0.1nm |
| Photometric Accuracy | ±0.2% τ |
| Photometric Repeatability | 0.1% τ |
| Stray Light | ≤0.02% τ |
| Stability | 0.0003A/h@500nm |
| Photometric Mode | T,A,C,E |
| Wavelength Setting | Automatic |
| Photometric Display Range | -4~4A |
| Display Mode | Touch LCD Screen (10 inches) |
| Detector | Import Silicon Photodiode |
| Light Source | Import Deuterium Lamp & Tungsten Halogen Lamp |
| Power Requirement | AC 220V/50Hz 110V/60Hz |
| Dimensions(W*D*H) | 650×430×240mm |
| Weight | 21Kg |
