MX-S+ Digital Vortex Mixer
The MX-S+ is a heavy-duty digital vortex mixer equipped with a high-efficiency brushless DC motor, LCD parameter display, and dual touch/continuous mixing modes for rapid sample homogenization from 100 to 3000 rpm.
100 – 3000 rpm Digital Speed | Touch & Continuous Modes | Brushless DC Motor | LCD Screen Display
Key Features
- Digital Speed & Time Display: Clear LCD screen displays real-time speed and remaining time for standardized mixing routines.
- Dual Operating Modes: Easy selection between pressure-activated Touch mode and Continuous running mode.
- Brushless DC Motor: Delivers robust rotational torque, spark-free operation, and extended service life without carbon brush wear.
- Wide Speed Range: Adjustable from gentle shaking (100 rpm) to vigorous vortexing (3000 rpm) with 4.0 mm orbital motion.
- Stable Heavy Base: Sturdy cast iron base with vibration-absorbing silicone feet prevents benchtop displacement.
- Extensive Accessory Compatibility: Supports standard cups, microplate clamps, flask holders, and foam tube adapters.
Technical Specifications
| Specification | MX-S+ |
|---|---|
| Speed Range | 100 – 3000 rpm |
| Speed & Time Display | LCD |
| Orbital Amplitude | 4.0 mm |
| Operating Modes | Touch Mode, Continuous Mode |
| Timer Range | 1 s – 99 min 59 s |
| Motor Type | Brushless DC Motor |
| Input Voltage / Power | DC 24V / 25 W |
| Power Supply | 100-240 V, 50/60 Hz |
| Dimensions (L × W × H) | 160 × 146 × 115 mm |
| Weight | 3.4 kg |
| Permissible Ambient Environment | 5 – 40 °C, 80% RH |
| Protection Class | IP21 |
Note: Compatible with all standard MX series vortex accessories including microplate clamps and multi-tube foam racks.
