Product Information
| Code | Description |
| AS-08060-00 | Mini-6K AC100 ~ 240V 50~60Hz |
| AS-08070-00 | Mini-7K AC100 ~ 240V 50~60Hz |
| AS-08080-00 | Mini-10K AC100 ~ 240V 50~60Hz |
Technical Data
| Model | Mini-6K | Mini-7K | Mini-10K |
| Power requirement | 30W | 30W | 40W |
| Relative centrifugal force (RCF) | 2,000 x g | 2,300 x g | 5,000 x g |
| Max.rotational speed | 6,000rpm | 7,000rpm | 10,000rpm |
| Rotors | 6×1.5/2.0ml angle rotor 2 – 8×0.2ml strip rotor Rotor for slide |
6×1.5/2.0ml angle rotor 2-8×0.2ml strip rotor |
6×1.5/2.0ml angle rotor |
| Dimensions | 175x148x118mm | 175x148x118mm | 175x148x118mm |
| Weight | 0.7kg | 0.7kg | 0.7kg |
| Power | AC100-240V | AC100-240V | AC100-240V |
Accessories
| Code | Description |
| AS-08061-01 | Allen wrench |
| AS-08061-02 | 6-1.5/2.0ml rotor |
| AS-08061-03 | 2-8×0.2ml strip rotor |
| AS-08061-04 | Slide rotor |
| AS-08061-05 | Adapters for 0.5/0.6ml tubes |
| AS-08061-06 | Adapters for 0.2ml tubes |
