Three protection: operator, sample and environment. Airflow system: 70% air re-circulation, 30% air exhaust A2 Cabinet is suitable for working with microbiological research in the absence of volatile or toxic chemicals and radio nuclide.
Advantages:
1. Motorized front window.
2. Large LCD display, all information displayed.
3. Automatic air speed adjustable with filter block.
4. Side & back wall is made up of single piece stainless steel.
5. Interlock function: UV lamp and front window; UV lamp and blower, fluorescent lamp; Blower and front window.
6. Front 10°slanted to offer operator comfort while working for long time, reduce glare and maximize reach into the work area.
| Model | 11235BBC86(3′) | 11236BBC86(6′) | |
| External Size(W*D*H) | 1087*775*2265mm | 1873*775*2295mm | |
| Internal Size(W*D*H) | 910*600*660mm | 1700*600*660 mm | |
| Work Surface Height | 750mm | ||
| Max Opening | 520mm (21”) | 550mm (22”) | |
| Tested Opening | Safety height 200mm (8”) | Safety height 200mm (8”) | |
| Airflow Volume | Inflow | 348m3/h(205cfm) | 649m3/h(382cfm) |
| Down flow | 65%:649m3/h(382cfm) | 60%:1212m3/h(713cfm) | |
| Exhaust | 35%:348m3/h(205cfm) | 40%:649m3/h(382cfm) | |
| Front Window | Motorized. Two-layer laminated toughened glass ≥5mm. Anti UV | ||
| HEPA Filter | Two, 99.999% efficiency at 0.3um, filter life indicator | ||
| Filter Guard Type | Aluminum alloy frame | ||
| Noise | NSF 49≤61 dB/EN 12469≤58 dB | ||
| Illumination | ≥1000Lux | ||
| Display | LCD Display | ||
| Waterproof Socket | 2, Total consumption:≤500W | ||
| Tap | Water tap*1, Gas tap *1 | ||
| Ground Resistance | ≤ 0.10Ω | ||
| Power Supply | AC220/110V±10%, 50/60Hz ±1Hz, Full load Amps: 9A, BTU/Hr: 1689 | ||
| Consumption | 300W | 500W | |
| Alarm | Abnormal airflow velocity; Filter replacement; Front window at unsafe height | ||
| DC Motor | One ECM motor, 110V& 220V acceptable, Speed adjustable,
high efficiency and low power consumption |
||
| Material | Working area: 304stainless steel/ Frame and Decorative Plate:
cold-rolled steel with anti-bacteria power coating |
||
| UV Lamp | 18W | 40W | |
| Germicidal UV lamp, Emission of 253.7 nanometers for most efficient decontamination | |||
| Illuminating Lamp | 10W*2 | 22W*2 | |
| LED lamp | |||
| Standard Accessory | Illuminating lamp, UV lamp *2, Base stand, SS water & gas taps, Drain valve,
Waterproof sockets, Stainless Steel I.V. Bar with 10 hooks |
||
| Optional Accessory | Armrest, Airflow tester, Formalin fumigation sterilizer,Infrared sterilizer,
Adjustable base stand, Remote control, Electric height adjustable base stand |
||
| Package Size (W*D*H) | 1220*1000*1840mm | 2020*1080*1900mm | |
| Gross Weight | 270kg | 363kg | |
