Description
- L1650 series biological microscopes are equipped with achromatic objectives or semi-plan achromatic and wide field eyepieces. They provide clear image and wide field. They can be used for biology medicine and agriculture area widely. They are the ideal instruments in medical treatment and scientific research.series biological microscopes are equipped with achromatic objectives or semi-plan achromatic and wide field eyepieces. They provide clear image and wide field. They can be used for biology medicine and agriculture area widely.
- Features
▲ With wide field eyepieces, achromatic objectives or semi-plan achromatic, the field of view is widely and clearWith wide field eyepieces, achromatic objectives or semi-plan achromatic, the field of view is widely and clear▲ Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μmz▲ 6Volt 20Watt Halogen lamp with brightness control
Specification
- Standard Configuration
ModelL1650AL1650BEyepieceWide field WF10X(Φ18mm)ObjectiveAchromatic 4X/0.10Semi-plan achromatic 4X/0.10Achromatic 10X/0.25Semi-plan achromatic 10X/0.25Achromatic 40X/0.65(Spring)Semi-plan achromatic 40X/0.65(Spring)Achromatic 100X/1.25(Spring, oil)Semi-plan achromatic 100X/1.25(Spring, oil)Eyepiece tubeBinocular(Inclination of 30˚)Focus systemCoaxial coarse/fine focus, with tension adjustable and up stop minimum division of fine focusing: 2μm.NosepieceQuadruple(Backward ball bearing inner locating)StageDouble layer mechanical (Size:135mmX125mm, Move range: 75mmX35mm)Abbe condenserN.A.1.25 Rack & pinion adjustableFilterBlue filterFrosted filterCollectorFor halogen lampLight source6V 20W Halogen lamp with brightness control
