| Characteristics: |
| * Measurement of light scatter and decay of the insoluble particles suspended in water or transparent liquids. |
| * Quantitative analysis of particle contents. |
| |
| Specification: |
| * Light source: Tungsten halogen lamp 6V, 10W |
| * Receiving element: Silicon photocell |
* Measurement ranges NTU:
0.00-50.0; 50.1-200; 201-2000 (automatic range switchover) |
| * Readings display: 4 digits LED display |
| * Allowable error of indication: |
a) 0-200NTU: ≤±8%
b) 201-2000NTU: ≤±6% |
| * Zero Drift: : ≤±3%%FS |
| * Stability of indication: : ≤±1% |
| * Repeatability: ≤2% |
| * Sample bottle: Ø25 mm*95 mm |
| * Sample volume: 20--30 ml |
| * Weight (Gross): 9kg |
| * Overall dimensions: 460mm*430mm*250mm |
